1.291/4
Brush Holders - Starter Motor
REPLACEMENT CODES
AIM
Cargo
Fiat
J&N
Magneti Marelli
Wagner
WAI
SPECIFICATIONS
Number of Brushes
4
Voltage
12 v
Brushes Width (mm)
6
Brushes Height (mm)
15
Brushes Length (mm)
16.5
Power
1,4 kW
Type
M70R
DENSO / NIPPONDENSO
FORD / MOTORCRAFT
MAGNETI MARELLI
ALFA ROMEO
145 (1.4), 146 (1.4), 155 (1.8), 156 (2.0), 164 (2.0), 166 (2.0), GT (1.8), GTV (2.0), Spider (2.0)
FIAT
Brava (1.6 16V EL / 1.6 16V SX / 1.8), Bravo (1.6 / 1.8 / 2.0), Coupé (1.8 / 2.0), Doblò (1.9), Grand Punto (1.6), Marea (1.6 i 16V / 1.6i 16V / 2.4), Multipla (1.6 16 V Bipower / 1.6 16V), Palio (1.9), Palio Weekend, Punto (1.9), Strada (1.9), Tempra (1.8 / 2.0), Tipo (1.6), Uno (1.3)
FORD
Courier (1.3), Fiesta (1.3)
LANCIA
Dedra (1.6 16V), Lybra (1.6 16V)
MAZDA
121 (1.3)
NISSAN
Primera (2.0)
SUZUKI
SX4 (1.9 DDiS)
